1
|
00-0031-C
|
# In Diagram: 1
00-0031-C $220.04/ea |
$0.00
|
X Axis Belt Cover
|
| $220.04/ea |
$0.00
|
|
|
|
|
|
2
|
6910
|
# In Diagram: 2
6910 $80.30/ea |
$0.00
|
Upper Drive Shaft Nice Bearing
|
| $80.30/ea |
$0.00
|
|
|
|
|
|
3
|
6908
|
# In Diagram: 3
6908 $83.05/ea |
$0.00
|
Lower Drive Shaft Bearing
|
| $83.05/ea |
$0.00
|
|
|
|
|
|
4
|
STEP MTR ASSY
|
# In Diagram: 4
STEP MTR ASSY $540.38/ea |
$0.00
|
Stepper Motor - HT34-474-001
|
| $540.38/ea |
$0.00
|
|
|
|
|
|
5
|
00-1000-A
|
# In Diagram: 5
00-1000-A $41.59/ea |
$0.00
|
Motor Spacer
|
| $41.59/ea |
$0.00
|
|
|
|
|
|
6
|
00-0008-A
|
# In Diagram: 6
00-0008-A $52.44/ea |
$0.00
|
Gantry Bearing Mount
|
| $52.44/ea |
$0.00
|
|
|
|
|
|
7
|
00-0012-A
|
# In Diagram: 7
00-0012-A $77.12/ea |
$0.00
|
X Axis Motor Plate
|
| $77.12/ea |
$0.00
|
|
|
|
|
|
8
|
00-0014-A
|
# In Diagram: 8
00-0014-A $33.91/ea |
$0.00
|
X Axis Motor Backing Nut
|
| $33.91/ea |
$0.00
|
|
|
|
|
|
9
|
TWB-1018
|
# In Diagram: 9
TWB-1018 $8.58/ea |
$0.00
|
Thrust Washer
|
| $8.58/ea |
$0.00
|
|
|
|
|
|
10
|
TRC-1018
|
# In Diagram: 10
TRC-1018 $6.60/ea |
$0.00
|
Thrust Washer
|
| $6.60/ea |
$0.00
|
|
|
|
|
|
11
|
01-0020-A
|
# In Diagram: 11
01-0020-A $32.67/ea |
$0.00
|
X Axis Motor Cable Bracket
|
| $32.67/ea |
$0.00
|
|
|
|
|
|
12
|
10XL037 x 3/8
|
# In Diagram: 12
10XL037 x 3/8 $88.74/ea |
$0.00
|
HVAC Carriage Motor Pulley
|
| $88.74/ea |
$0.00
|
|
|
|
|
|
13
|
210XL037K
|
# In Diagram: 13
210XL037K $23.32/ea |
$0.00
|
Carriage Belt
|
| $23.32/ea |
$0.00
|
|
|
|
|
|
14
|
72XL037 x 5/8
|
# In Diagram: 14
72XL037 x 5/8 $70.52/ea |
$0.00
|
Stand Alone Drive Shaft Pulley
|
| $70.52/ea |
$0.00
|
|
|
|
|
|
15
|
02-0089-A
|
# In Diagram: 15
02-0089-A $41.59/ea |
$0.00
|
Double Track Bracket End Mount
|
| $41.59/ea |
$0.00
|
|
|
|
|
|
16
|
02-0088-B
|
# In Diagram: 16
02-0088-B $51.54/ea |
$0.00
|
Double Track Mounting Bracket
|
| $51.54/ea |
$0.00
|
|
|
|
|
|
17
|
18L050x1/2
|
# In Diagram: 17
18L050x1/2 $70.76/ea |
$0.00
|
Lower Drive Shaft Pulley,18 Tooth Pulley 1/2" Bore, 1/8"kw, Alum
|
| $70.76/ea |
$0.00
|
|
|
|
|
|
18
|
322L050K
|
# In Diagram: 18
322L050K $46.73/ea |
$0.00
|
Shaft to Shaft Belt
|
| $46.73/ea |
$0.00
|
|
|
|
|
|
18
|
345L050
|
# In Diagram: 18
345L050 $45.49/ea |
$0.00
|
Shaft to Shaft Belt
|
| $45.49/ea |
$0.00
|
|
|
|
|
|
19
|
18L050x5/8
|
# In Diagram: 19
18L050x5/8 $70.76/ea |
$0.00
|
Upper Drive Shaft Pulley
|
| $70.76/ea |
$0.00
|
|
|
|
|
|
20
|
11-0017-C
|
# In Diagram: 20
11-0017-C $215.84/ea |
$0.00
|
Gantry End Channel
|
| $215.84/ea |
$0.00
|
|
|
|
|
|
21
|
00-0019-A
|
# In Diagram: 21
00-0019-A $65.98/ea |
$0.00
|
Gantry Lower Drive Shaft
|
| $65.98/ea |
$0.00
|
|
|
|
|
|
22
|
S25FY9-PC50031
|
# In Diagram: 22
S25FY9-PC50031 $52.58/ea |
$0.00
|
Fairloc Clamp Collar
|
| $52.58/ea |
$0.00
|
|
|
|
|
|
23
|
77R8
|
# In Diagram: 23
77R8 $18.66/ea |
$0.00
|
Lower Drive Shaft Bearing
|
| $18.66/ea |
$0.00
|
|
|
|
|
|
24
|
D-8H-00-002-0300-A
|
# In Diagram: 24
D-8H-00-002-0300-A $53.98/ea |
$0.00
|
Bearing Housing
|
| $53.98/ea |
$0.00
|
|
|
|
|
|
25
|
00-0016-A
|
# In Diagram: 25
00-0016-A $23.14/ea |
$0.00
|
X Axis Track Bracket
|
| $23.14/ea |
$0.00
|
|
|
|
|
|
26
|
00-0015-A
|
# In Diagram: 26
00-0015-A $307.59/ea |
$0.00
|
Proxy Mounting Angle
|
| $307.59/ea |
$0.00
|
|
|
|
|
|
27
|
00-0052-B
|
# In Diagram: 27
00-0052-B $84.81/ea |
$0.00
|
Linear Bearing Mounting Bar
|
| $84.81/ea |
$0.00
|
|
|
|
|
|
28
|
HGH20CAZ0C
|
# In Diagram: 28
HGH20CAZ0C $125.40/ea |
$0.00
|
Torch Holder Linear Car
|
| $125.40/ea |
$0.00
|
|
|
|
|
|
29
|
00-0051-A
|
# In Diagram: 29
00-0051-A $23.14/ea |
$0.00
|
Linear Bearing Jack Bar
|
| $23.14/ea |
$0.00
|
|
|
|
|
|
30
|
00-0009-A
|
# In Diagram: 30
00-0009-A $52.44/ea |
$0.00
|
Gantry End Channel Mounting Block
|
| $52.44/ea |
$0.00
|
|
|
|
|
|
31
|
2040 X 1NS
|
# In Diagram: 31
2040 X 1NS $244.55/ea |
$0.00
|
40 Tooth 1" wide 1/2" Bore Gear
|
| $244.55/ea |
$0.00
|
|
|
|
|
